LARGE VOLUME METROLOGY

Laser Tracker 3D Scanning Service for Large Components Across South India

Request Consultation Talk to Specialist
"
THE METROLOGY CHALLENGE

When structures span metres instead of millimetres, conventional measurement systems reach their limits.

Large scale 3D scanning for heavy engineering and industrial parts requires a fundamentally different approach to coordinate metrology.

With FARO Vantage Laser Tracker technology, APJ 3D breaks the boundaries of volume restrictions, bringing absolute precision to your largest structural assemblies.

Aerospace Structures

Wing alignments, fuselage assembly, and complex jig calibration.

Heavy Machinery

Earthmoving equipment, massive presses, and large tooling inspection.

Turbine Components

Wind, hydro, and gas turbine blade dimensional verification.

Industrial Frames

Welded structures, plant infrastructure, and multi-station assemblies.

HARDWARE

FARO Vantage Showcase

Working Range & Accuracy

  • 150–300m Range
  • Sub-millimetre Accuracy

6DoF Probing

  • Hidden Feature Capture
  • Recessed Datums
  • Internal Geometry

Real-Time Dynamic Tracking

  • Live Alignment Monitoring
  • Continuous Measurement

Software Integration

  • CAM2 Software
  • PolyWorks Inspector
  • Metrolog X4
ASSEMBLY ALIGNMENT

Precision Assembly &
Jig Calibration

For large-scale manufacturing, the foundation of quality is absolute alignment. Our laser tracker services enable real-time monitoring and adjustment of critical assemblies.

  • Automated Jig & Fixture Verification
  • Live Robot Calibration
  • Multi-Component Mating Analysis
Precision Jig and Fixture Assembly Calibration
Sub-mm Tolerance Control
LONG RANGE METROLOGY

Large Volume
Dimensional Capture

Spanning up to 150m radially (300m total volume), we digitize massive environments, production lines, and structural components without compromising precision.

  • Plant Layout & Machine Positioning
  • Structural Deformation Analysis
  • Ship Building & Civil Engineering
Large Volume 3D Dimensional Capture
150m Spherical Working Radius
AEROSPACE PROJECT CASE STUDY

Aerospace Project Experience

Demonstrated capability in zero-failure aerospace environments.

CASE STUDY #001

Jet Engine Casing
Multi-Stage Alignment

APJ 3D was contracted to perform highly critical alignment of a commercial jet engine casing assembly. The requirement mandated positional accuracy within 0.050mm over a 4-metre volumetric space.

01
The Challenge
Stack-up tolerances in 5 separate casing rings caused internal blade clearance issues that conventional tools could not resolve.
02
The Solution
Using FARO Vantage, we established a master datum network, mapping all dowel holes and mating flanges in a single coordinate frame.
03
The Outcome
Final assembly achieved 0.015mm average deviation — 70% better than the specified tolerance. Zero rework required.
0.015
MM TOLERANCE
ACHIEVED PRECISION
MEASUREMENT VOLUME
4metre
RINGS MAPPED
5
REWORK
Zero
ALSO APPLIED IN: Defence Structures Power Turbines Satellite Assembly Launch Vehicle Components
WHY APJ 3D

The Engineering
Advantage

Six reasons why industry leaders choose APJ 3D for their most demanding dimensional challenges.

01
True Portability
IP52 rated systems operable in harsh foundry or welding environments.
02
Global Datums
Link multiple tracker positions together for immense coordinate systems.
03
Dynamic Target Acquisition
ActiveSeek technology instantly finds and locks onto the SMR.

Integrated Analysis

Compare built structures directly to master CAD in real-time — identify deviations instantly without post-processing delays.

Real-time CAD Comparison

Reverse Engineering

Extract raw surface and geometric data for massive legacy tooling.

Certified Metrologists

Experienced application engineers handling complex coordinate setups.

Technical Service Overview Reviewed by APJ 3D Engineering Desk • Updated September 2026

What is Laser Tracker 3D Scanning Services?

Dimensional Inspection is the formal verification of physical components against engineering drawings and CAD models using bridge CMMs, portable articulated arms, optical comparators, and laser trackers.

When to Select This Service

Choose dimensional inspection for First Article Inspection Reports (FAIR), PPAP Level 3 supplier submissions, batch quality audits, and shop-floor fixture alignment adhering to ASME Y14.5 and ISO 1101 standards.

Laser Tracker 3D Scanning Services Technical Specifications

Technical Capabilities & Verification Standards

Verified engineering parameters, hardware precision, and compliance benchmarks applied across all deliverables.

Engineering Parameter APJ 3D Capability & Precision Range Compliance Standard / Verification
Measurement Equipment Bridge CMM (ZEISS / Renishaw), Portable Romer Arms, Laser Trackers, Vision Measuring Systems ISO 10360 Precision Compliance
Measurement Uncertainty Bridge CMM: E0 = 1.5 + L/350 µm; Portable Arm: ±0.025 mm; Laser Tracker: ±0.015 mm/m NABL / ISO 17025 Calibrated Standards
GD&T Verification Full ASME Y14.5 & ISO 1101 evaluation (Profile, True Position, Runout, Parallelism, Perpendicularity) Automated Inspection Programs
Inspection Frameworks AS9102 FAIR (Aerospace), AIAG PPAP Level 3 (Automotive), ISO 9001 Batch Quality Audits Standard Ballooned Drawing Reports
Inspection Environment Class 10,000 Temperature & Humidity Controlled Metrology Laboratory (20°C ± 0.5°C) Standard Reference Metrology Environment
Software & Reporting ZEISS CALYPSO, PolyWorks Inspector, PC-DMIS, Geomagic Control X Comprehensive Graphical & Tabular PDFs
Turnaround Time 24 to 48 Hours for standard First Article & batch inspection lots Pan-India On-Site CMM Arm Support

Related Services

Bluelight 3D Scanning Structured Light 3D Scanning Industrial Handheld 3D Scanning White Light 3D Scanning Industrial CT Scanning 3D Scanning
FAQ

Frequently Asked Questions

What is included in a First Article Inspection Report (FAIR)?
A FAIR includes a ballooned engineering drawing matching every dimension to an itemized inspection table, raw actual values, upper/lower tolerances, out-of-spec flags, and tool calibration certificates per AS9102 or customer templates.

Can you inspect parts according to PPAP Level 3 requirements?
Yes. We generate full dimensional results, Gage R&R studies, process capability studies (Cp/Cpk), material test reports, and Part Submission Warrants (PSW) for automotive Tier-1 supplier audits.

Do you provide on-site inspection for large tooling and weld fixtures?
Yes. Our metrology team deploys portable articulated arms and laser trackers directly to your manufacturing plant for on-site jig alignment, weldment inspection, and stamping die verification.

How do you establish datum reference frames for GD&T inspection?
We align physical components using primary, secondary, and tertiary datum features (planes, cylinders, holes) as specified on engineering drawings per ASME Y14.5M, eliminating alignment ambiguity.

What turnaround time can we expect for batch inspection?
Standard First Article inspections deliver in 24 to 48 hours. Ongoing production batch inspections can be scheduled with dedicated capacity and automated CMM routines.

Need to Measure What Conventional Tools Cannot Reach?

Laser Tracker 3D Scanning Services for Large Scale Metrology, Aerospace Alignment, and Precision Inspection Across India.

Get Free Consultation Send Component Details
